NE555 DW44 Monostable Circuit Module - Falling Edge Trigger for Delay Switch Timer | DIY Electronics, Robotics & Timing Control Projects

Product Description

1.Power Supply Voltage:DC 5-15V2.Quiescent:5V-3mA;12V-8mA3.Output Driving Current:200mA (max)4.Function:1)Falling edge trigger:after power on initial state is low level output (steady state);after trigger it will output high level;after delay for some time output will become low level2)Delay time will start to count from trigger signal falling edge5.Application:delay switch,mechanical switch contact anti-shaking,timer,pulse fractional frequency,pulse widening6.Using Method:adjusting multiturn potentiometer,and output delay time is adjustable (10ms-20s);anti-clockwise adjust time will decrease,clockwise adjust time will increasePackage Included:1PCS NE555 DW44 Monostale Circuit Module Falling Edge Trigger For Delay Switch Timer CA
