Oumefar Timer Relay Switch AC/DC 12-240V DIN Rail Mount - Mini Asymmetric Cycle Delay ON/Off Control for Industrial Automation, HVAC Systems & Lighting Control

Product Description

Model: GRT8-S2 Rated supply voltage: AC/DC 12-240V(50-60Hz) Power consumption: AC 0.09-3VA / DC 0.05-1.7W Delay time range: 0.1s-100days, NO, NC Setting method: knob Setting accuracy: 10% Repeated accuracy: 0.2% Temperature fluctuation error: 0.05%/℃, at = 20℃ Output contact: 2 x SPDT, 2 x 16A/AC1 Minimum switching power: 500mW Power indicator: Green LED Output relay indication: Red LED Mechanical life: 1x107 Electrical life: 1x106 Reset time: Max 200ms Working temperature: -20℃~55℃ Storage temperature: -35℃~75℃ Mounting method: 35mm DIN rail Protection grade: IP20 Wiring capability: 1x2.5mm2 or 2x1.5mm2 Dimensions: 90*18*64mm / 3.54*0.71*2.52in Package weight: Approx. 96g/3.4oz
