Jectse Timer Relay Module, 3V-7V DC, 3A, Normally Open, Surface Mount, -40°C to 85°C, Automatic Operation, Adjustable Cycle Timer Control Relay Time Delay Switch Module - Perfect for Industrial Automation, Home Appliances, and DIY Electronics Projects

Product Description

Features:This time delay relay can be powered with low voltage, minimum to 3V.Commonly-used 3.7V lithium batteries, 5V power banks, switching power supply can be used to power this board.Widely used to control motors, light bulbs, LED belts, DC motor, small pumps, etc.Output optical coupling isolation improves anti-interference ability. The module uses industrial level circuit board, and set parameters will be saved after power failure.Specification:Working current: DC 3V~7VVoltage range with jumper: 3 V~5.5V Voltage range without jumper: 3.8V~7V source: DC 3V~12V (commonly use power supply positive , button, PNP sensor, PLC , etc.)Output capacity: Can control equipment within DC 30V3A or AC 220V3AQuiescent current: 15mA Working current: 30mAService life: >100,000 timesOperating temperature: -40℃~85℃Size: 64.2*34.8*15mm / 2.5*1.4*0.6inWeight: 22g / 0.8oz (approx.)Package list:1 * Module
